Code: Section 'Device' Identifier 'Radeon' Driver 'radeon' #Option 'DRI' '2' #Option 'AccelMethod' 'exa' Option 'NoAccel' 'True' EndSectionWhat these config options do is drive the card at maximum AGP-speed but turn off the radeon hardware specific acceleration methods. The boost of bandwith from 133 MB/s (PCI mode, as in radeon.agpmode=-1) to 2133 MB/s (AGP-x8 mode, as in radeon.agpmode=8) outweighs the loss of specific acceleration a lot, at least on my G5 machine with its 'ATI Radeon 9600 AP (AGP)' (ChipID = 0x4150).

You have to check first what maximum AGP-speed your card and your AGP-Northbride support. Then adjust the radeon.agpmode=x boot-parameter accordingly. On my G5 it's radeon.agpmode=8, on my PowerBook G4s it would be radeon.agpmode=4.

If this wors correctly you will get following messages from your kernel. Code: $ dmesg grep -i agp 0.000000 Found U3-AGP PCI host bridge. @rican-linux: Glad to hear that this works with your setup too! What graphic cards are in your iBook & Powerbook? I only got Radeon r300-class cards, so I can't make any statements about different hardware. I can only suppose this can improve performance on other rx00-card systems too if the machine has at least AGPx2 and an otherwise hardware acceleration is not. The only machine where I get.

full. HW-acceleratio n is my PowerBook 5,8. There I don't need the 'NoAccel'-option in xorg.confg and can drive the card with AGPx4. This does not work on a PB 5,6 or 5,4 which I had. There must be some subtile differences between the 5,8 model and the other ones.

I will continue playing around with some xorg.conf options, e.g. 'AccelMethod', 'ColorTiling', 'ColorTiling2D' look interesting. Let's see what leads to a GPU-lockup and if not to more performance. Code: rican-linux@Lubuntu-G5:$ dmesg grep -e radeon -e drm -e agp 5.725462 Linux agpgart interface v0.103 7.366602 agpgart-uninorth 0000:f0:0b.0: Apple U3 chipset 7.390331 drm Initialized drm 1.1.0 20060810 7.438792 agpgart-uninorth 0000:f0:0b.0: configuring for size idx: 64 7.438943 agpgart-uninorth 0000:f0:0b.0: AGP aperture is 256M @ 0x0 7.525634 drm radeon kernel modesetting enabled.

7.525700 fb: switching to radeondrmfb from OFfb ATY,Simone 7.528397 fb: switching to radeondrmfb from OFfb ATY,Simone 7.529583 radeon 0000:f0:10.0: enabling device (0006 - 0007) 7.530140 drm initializing kernel modesetting (RV350 0x1002:0x4150 0x1002:0x4150 0x00). 7.530164 drm register mmio base: 0xA0000000 7.530166 drm register mmio size: 65536 7.530210 radeon 0000:f0:10.0: Invalid PCI ROM header signature: expecting 0xaa55, got 0x0000 7.622759 drm Not an x86 BIOS ROM, not using. Code: $ cat /var/log/Xorg.0.log grep -i render 40.154 (WW) RADEON(0): Direct rendering disabled 40.236 (EE) AIGLX: reverting to software renderingMeans the DRI2-infrastucture is not used to display graphics but the framebuffer. But with DRI2 turned off the Radeon cards no longer freeze when using the intended AGP-x4 or AGP-x8 mode. That's what is causing the 'speed boost', because the maximum bandwith for accessing the graphics card is so much faster than plain PCI-mode.

Ideally DRI2 or DRI3 can be used AND the appropriate AGP-mode is autodeteced. Which is normally the case on Radeon cards on x86 PC-boards. And which magically works on your PowerMac G5 7,2 and my PowerBook G4 5,8 but not on other hardware-combiations. Don't know if variations of the Apple U3/U4 northbridge in the different PPC-Macs or specific Radeon cards are to blame but enabling DRI seems a very delicate matter.
